Disassembly Recommendations

1. How to disassemble?

1.1 Remove the limit pin

Pull down the limit pin to detach it from the upper limit hook.

1.2 Unscrew the connecting bolt

Rotate the connecting bolt counterclockwise until it is completely detached from the upper fixed thread.

1.3 Separate the lower part

Gently pull down the lower part of the pipette to separate the internal magnetic connection structure.

tip

Follow the disassembly recommendations provided in this manual, otherwise, the pipette may be damaged.
